F-15E 20mm Gun System

M61A1 Six-barrel Gatling Gun and Feed System
The F-15E 20mm Gun System on the same principle as our other 20mm Gatling aircraft systems. The M61A1 gun is mounted in the aircraft’s starboard wing root, aft of the engine inlet. The linear linkless ammunition storage container is mounted in a vertical orientation near the centerline of the aircraft.
Our lightweight linear ammunition feed system provides high reliability and maximum round capacity for aircraft’s allotted space envelope. The F-15E feed system is fully compatible with all M-50 series and the improved PGU-28/B ammunition, as well as our M61A2 gun.
F-15E 20mm Gun System Specifications

Weight (total)
Gun
Feed System
Ammunition (full)

769 pounds (349 kg)
248 pounds (112.5 kg)
236 pounds (107 kg)
281 pounds (127.5 kg)

Rate of fire

4,000/6,000 shots per minute

Ammunition capacity

500 rounds

Ammunition type

M50- & PGU-series ammunition

Feed system

Linear linkless, closed loop

Drive system

Hydraulic
